FRAMESET

Frame

Rangefinder Aluminum

Fork

SR Suntour XCM32 Boost, Coil, NLO, DS, 120 mm

Color

Silver

Rear Shock

N/A

DRIVETRAIN

Front Derailleur

N/A

Rear Derailleur

microSHIFT Advent X M6205

Cassette

microSHIFT Advent X H104 11–48t, 10-speed

Chain

Shimano HG54

Crankset

FSA Alpha Drive, 30t, FSA 124.5 mm bottom bracket

Shifter

microSHIFT Advent X M9605

Brakes

Shimano MT200 OR Tektro M520

Rotors

Shimano RT10 Center Lock rotors (160 mm)

COMPONENTS

Headset

FSA Orbit NO.57B 1.5 ZS

Stem

Salsa Guide 31.8, 60 mm, 6d

Handlebar

Salsa Salt Flat 31.8, 750 mm width XS–SM; Salsa Rustler 31.8, 800 mm width M–XL

Grips

Salsa File Tread

Seatpost

Salsa Guide 30.9, 0 offset

Saddle

WTB Volt Medium, Steel, 142 x 265 mm

WHEELS

Front Wheel

Shimano MT400 Center Lock 15 x 110 mm TA hub, WTB ST i40 32h 27.5" rim

Rear Wheel

Shimano MT200 Center Lock 10 x 141 mm QR hub, WTB ST i40 32h 27.5" rim

Tires

Maxxis Rekon 27.5 x 2.8", EXO, Wire Bead (not tubeless compatible)

WEIGHT

Complete Bike Weight

33 lb (with tubes, no pedals) for Medium

Design Wheel/Tire Sizes

27.5 x 2.8–3.0

Alternate Wheel/Tire Sizes

29 x 1.9–2.6

Suspension Fork Length (Travel)

100–130 mm

Fork Offset

46 mm

Headset, Upper

ZS44

Headset, Lower

ZS56

Seatpost

30.9 mm

Seatpost Collar

35.0 mm

Dropper Compatible (Routing)

Yes (internal)

Front Derailleur Clamp

N/A

Front Derailleur Type

N/A

Bottom Bracket

73 mm BSA, threaded

Crankset (Max Ring)

Boost 148 52 mm chainline only (32t max)

Rear Brake (Rotor)

74 mm post mount (160–180 mm rotor)

Rear Spacing

141 x 10 mm QR

Derailleur Hanger

FS2361

Rear Rack Mounts

Yes. Salsa Post-Lock seatpost collar required.

Fender Mounts

No

Water Bottle Mounts

2

Downtube Accessory Mounts

1

Top Tube Mounts

Yes, compatible with Salsa EXP Series Top Tube bag.
